Hastelloy Sheet Plate in Oman

Country » Hastelloy Sheet Plates in Oman

Hastelloy Sheet Plate In Oman, Hastelloy Sheet, Hastelloy Plate, Hastelloy Plate Suppliers, Hastelloy Sheet Suppliers

Bhansali Enterprise is a matter of great pleasure to be one of the reputed Hastelloy Sheet Plates manufacturers and suppliers in Oman. Our commitment to quality has made us a brand that produces and delivers products of the highest quality that can be used in various demanding applications.

Hastelloy is a family of Nickel Molybdenum chromium-based superalloys that are widely used due to their good corrosion and high temperature performance. Our Hastelloy Sheet Plates are produced from these superior alloys and much attention is paid to them to give the best performance and durability. These sheet plates can be used where there is a call to use a material that is very resistant to conditions such as high temperatures.

Hastelloy Plates

The following are some of the features of Hastelloy Sheet Plates; these plates have a high resistance to corrosion from; chlorides, sulfuric acids and seawater. This makes them particularly suitable for chemical processing, petrochemical and marine industries. Furthermore, Hastelloy Sheet Plates do not undergo any change in their mechanical properties at high temperatures and, therefore, provide reliable service where other materials might fail.

In this regard, we adhere to the quality control measures that help manufacture high-quality Hastelloy Sheet Plates. The quality control measures include mechanical property tests, corrosion resistance tests, and product dimensions. This entails that every activity, from the purchase of raw materials to the final inspection of the finished product, is done in an orderly manner to achieve the set quality and productivity standards.

Hastelloy Sheet Plates produced by us are used in chemical processing, oil and gas, power generation, and marine industries. Because of their high efficiency and durability, they are applied in fields where high reliability and durability of the equipment are required.

We strive to provide our clients with Hastelloy Sheet Plates that are of great value and are very efficient. We have many experienced people ready to help or even create a solution according to your needs.

Hastelloy Plates Specifications in Oman

Standards ASTM B575 / ASME SB575
Dimensions ASTM, ASME, and API
Plate Width Range 30″ to 240″
Sheets Plates Thickness 7 gauge to 28 gauge or 3.664mm to .321mm
Plate Length Range Up to144″ Non-Standard or Longer Lengths Available Upon Request
Value added services Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.
Hardness Half Hard, Quarter Hard, Soft, Hard, Spring Hard
Form Coils, Foils, Rolls, Strip, Flats, Blank (Circle), Ring (Flange)

Available Variations in Hastelloy Sheet Plates in Oman

Super Duplex Sheet

Hastelloy Sheets in Oman

Super Duplex Plates

Hastalloy Plates in Oman

Super Duplex Coil

Hastelloy Alloy Coil in Oman

Super Duplex Strips

Hastelloy Strip in Oman

Super Duplex Foil

Hastelloy Foil in Oman

Super Duplex Circle

Hastelloy Circle in Oman

Hastelloy Plates Equivalent Gardes in Oman

STANDARD WERKSTOFF NR. UNS JIS EN
Hastelloy C22 2.4602 N06022 NW 6022 NiCr21Mo14W
Hastelloy C276 2.4819 N10276 NW 0276 NiMo16Cr15W

Chemical Composition of Hastelloy Sheet Plates in Oman

Grade C Mn Si S Co Ni Cr Fe Mo P
Hastelloy C22 0.10 max 0.50 max 0.08 max 0.02 max 2.50 max 50.015 min* 20.00 – 22.50 2.00 – 6.00 12.50 – 14.50 0.02 max
Hastelloy C276 0.10 max 0.50 max 0.50 max 0.15max 5.0 max 58.0 min 20.0 – 23.0

Mechanical Properties of Hastelloy Sheet Plates in Oman

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Hastelloy C22 8.69 g/cm3 1399 °C (2550 °F) Psi – 1,00,000 , MPa – 690 Psi – 45000 , MPa – 310 45 %
Hastelloy C276 8.4 g/cm3 1350 °C (2460 °F) Psi – 1,35,000 , MPa – 930 Psi – 75,000 , MPa – 517 42.5 %
