Hastelloy C276 and C22 Wires are two popular variations of nickel-chromium-molybdenum alloys, each with distinct features and properties. Both are available in wire form and are widely used in demanding industrial applications where exceptional corrosion resistance is required. Hastelloy C276 wires are known for their excellent overall corrosion resistance in aggressive environments. They offer resistance to a wide range of corrosive substances, including chloride ions, oxidizing and reducing acids, and even strong halides. This makes them ideal for applications in chemical processing, pulp and paper production, waste treatment, and various other industries where exposure to corrosive chemicals is prevalent.

On the other hand, Hastelloy C22 Wires are particularly renowned for their outstanding resistance to localized corrosion, such as pitting and crevice corrosion. They provide superior protection in harsh environments containing oxidizing acids, such as nitric acid and ferric chloride. Due to this exceptional localized corrosion resistance, Hastelloy C22 wires are often used in aggressive chemical environments, especially in applications where crevice corrosion poses a significant risk.

Hastelloy C-276 Wires

In terms of chemical composition, Hastelloy C276 Wires contains around 55% nickel, 16% chromium, 16% molybdenum, 5.5% iron, and smaller amounts of tungsten and cobalt, among other elements. Hastelloy C22, on the other hand, has approximately 56% nickel, 22% chromium, 13% molybdenum, 3% tungsten, and trace amounts of iron and cobalt, among others. These compositions contribute to their respective corrosion resistance profiles and mechanical properties.

Machining both Hastelloy C276 and C22 wires can be challenging due to their high strength and work-hardening tendencies. Carbide tools and low cutting speeds are commonly used to achieve satisfactory results and minimize tool wear.

Bhansali Enterprises Specifications Of Hastelloy C-276 Wires

Standard ASTM B574 / ASME SB574
Dimensions ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360
Length Cut Lengths: 0.125" to 72"
No Limit on Spooled Lengths
Diameter 0.0004" to 0.040"
10 microns to 1.0 mm
Other Sizes on Request
Wire Density 8.89 g/cm3
Ultimate Strength (≥ MPa):
580-750
Wire Resistance (μΩ.m):
as standard
Wire Elongation (≥ %):
28-30
Surface Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated
Tempers Tempers range from dead soft annealed to ultra spring temper
Welded Wire mesh Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch
Roll Length: 100feet or 150feet
Wire Mesh Weaving Methods plain weave, twill weave, dutch weave
Technique Cold Rolled, hot rolled
Condition M, Y, 1/2Hard
Offered in a wide range of packages including: Spool
Reel
Coil
Bobbin
Carrier
Custom packaging provided from as low as 1lb to 200lb tapered plastics
Form Filler Wire, Flat Wire, Coil Wire, Electrode Wire, Welding Wire, Wire mesh, Knitted wire mesh, filter mesh, mig wire, tig wire, spring wire, stranded and twisted wire
Test Certificates Tensile Testing
Hardness Testing
Metallographic Inspection / Investigation
Corrosion Testing
Chemical Analysis
Wrap Testing
Elevated Temperature Testing
Stress Rupture Testing (Creep)

LogoASME SB574 Hastelloy C-276 Wires Equivalent Grades

cta one shape 1
STANDARD WERKSTOFF NR. UNS JIS EN DIN ISO GOST OR
Hastelloy C276 2.4819 N10276 NW 0276 NiMo16Cr15W 17750 6208 ХН65МВУ ЭП760
Hastelloy C22 2.4602 N06022 NW 6022 NiCr21Mo14W

LogoChemical Composition of Hastelloy C-276 Wires

cta one shape 1
Grades C Mn Si S Co Ni Cr Fe Mo P
C276 0.010 max 1.00 max 0.08 max 0.03 max 2.50 max 50.99 min* 14.50 – 16.50 4.00 – 7.00 15.00 – 17.00 0.04 max
C22 0.010 max 0.50 max 0.08 max 0.02 max 2.50 max 50.015 min* 20.00 – 22.50 2.00 – 6.00 12.50 – 14.50 0.02 max

LogoMechanical Properties of Hastelloy C-276 Wires

cta one shape 1
Grades Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Hastelloy C276 8.89 g/cm3 1370 °C (2500 °F) Psi – 1,15,000 , MPa – 790 Psi – 52,000 , MPa – 355 40 %
Hastelloy C22 8.69 g/cm3 1399 °C (2550 °F) Psi – 1,00,000 , MPa – 690 Psi – 45000 , MPa – 310 45 %

Bhansali Enterprises Available Variations in Hastelloy C-276 Wires

Hastelloy C276 Welding Wire

Welding Wire

Hastelloy C276 Welding Wire

Hastelloy® Alloy C-276 Bright Wire

Bright Wire

Hastelloy® Alloy C-276 Bright Wire

Alloy 276 Wire Spool

Wire Spool

Alloy 276 Wire Spool

Nickel Alloy 276 Wire Coil

Wire Coil

Nickel Alloy 276 Wire Coil

C276 Hastelloy Mig Wire

Mig Wire

C276 Hastelloy Mig Wire

Hastelloy C-276 Woven Wire Mesh

Woven Wire Mesh

Hastelloy C-276 Woven Wire Mesh

Bhansali EnterprisesOther Types Of Hastelloy C-276 Wire

  • Hastelloy C276 Filler Wire
  • ASME SB574 Hastelloy C-276 Wire
  • Grade C-276 Hastelloy Wire Rope
  • Hastelloy C22 Ultra Fine Wires
  • Hastelloy C-276 Tig Wire
  • Hastelloy Alloy 276 Square Wire
  • Hastelloy C276 Wire Mesh Manufacturer
  • Hastelloy® Alloy C-276 Spool Wire
  • Hastelloy C-276 Welding Wire Price
  • UNS N10276 Wire
  • C276 Hastelloy Industrial Wires
  • Alloy 276 Spring Wire
  • Nickel Alloy 276 Wire Rope
  • C-276 Hastelloy Cold Heading Wire
  • Hastelloy C-276 Cold Drawn Wire
  • Hastelloy® Alloy C-276 Spring Hard Quality Wire
  • 2.4602 Wire
  • C-276 Hastelloy Welding Wire
  • ASTM B574 Hastelloy C-276 Woven Wire mesh
  • 2.4819 Wires
  • Alloy 276 Knitted Wire Mesh
  • Hastelloy C-276 Crimped Wire Mesh
  • Nickel Alloy 276 Wire Bobbin
  • Hastelloy C-276 Wire
  • Hastelloy Alloy 276 Wire Mesh
  • Hastelloy C276 Weld Mesh
  • Hastelloy C-276 Coil Wire
  • ASTM B574 C276 Hastelloy Wire
  • Hastelloy C22 Netting Wiremesh
  • Hastelloy C-276 Knitting Wire
  • Hastelloy® Alloy C-276 Wire cloth
  • Alloy 276 Mig Wire
  • Wire Mesh Hastelloy C-276
  • UNS N06022 Wire

Bhansali EnterprisesHastelloy C-276 Wires Technical Data

Bhansali EnterprisesHastelloy C-276 Wires Industrial Application

Applications of Hastelloy C276 and C22 wires span a wide range of industries. Both alloys are utilized in chemical processing plants, where their corrosion resistance ensures the safe handling of aggressive chemicals. They are also employed in pollution control systems, pulp and paper production, and waste treatment facilities. Additionally, these wires find use in oil and gas processing, power generation, and aerospace industries, where their exceptional resistance to various corrosive substances is highly valuable.

Shape
about three shape 4
Shape
Shape
  • Oil & Gas Industry

  • Power Plant Generation

  • Marine Industry

  • Petrochemical Industry

  • Chemical Industry

  • Aerospace Industry

  • Sugar Industry

Bhansali EnterprisesHastelloy C-276 Wires Price Details

Prices for Hastelloy C-276 Wire Products are very affordable. Please click on the request a quote button or Click Here to request the updated price list and ready stock information along with your requirement. Bhansali Enterprise Hastelloy C-276 maintains a stock of all standard items and can export them at the best price ASME SB574 C276 Hastelloy Wires, Coil Wire, Ribbon Wires, Wiremesh, Wire Bobbin etc.
