Stainless Steel 303 Wire is a type of austenitic stainless steel wire known for its excellent machinability and corrosion resistance. It contains a higher sulfur content than other austenitic grades, which promotes better machinability but may slightly reduce its corrosion resistance compared to Stainless Steel 304 or 316.

The main features of Stainless Steel 303 Wires include its exceptional machining capabilities, making it a popular choice for applications where complex shapes and precise tolerances are required. The addition of sulfur allows for improved chip breaking and reduced tool wear during machining processes. Moreover, it offers good strength and moderate corrosion resistance, making it suitable for various applications across different industries.

 Stainless Steel 303 Wires

In terms of corrosion resistance, Stainless Steel 303 wires perform well in mildly corrosive environments. However, they may not be as resistant to certain aggressive environments as other stainless steel grades, like 304 or 316, due to the higher sulfur content. For applications where corrosion resistance is a critical factor, it is advisable to choose a different grade with lower sulfur content.

The chemical composition of Stainless Steel 303 wires typically includes around 17-19% chromium and 8-10% nickel, similar to other austenitic stainless steels. Additionally, it contains approximately 0.15% sulfur and a maximum of 0.15% phosphorus, which contribute to its machinability.

Machining Stainless Steel 303 wires is relatively easy due to its sulfur content, which promotes improved cutting and chip breaking. It can be readily machined using various processes such as turning, milling, drilling, and threading. However, it is essential to use the appropriate cutting tools and maintain proper cutting speeds and feeds to achieve the best results.

Bhansali Enterprises Specifications Of SS 303 Wires

Standard ASTM A580, A313, A555, A493 / ASME SA580, SA313, SA555, SA493, AMS 5514
Dimensions ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360
Length Cut Lengths: 0.125" to 72"
No Limit on Spooled Lengths
Diameter 0.0004" to 0.040"
10 microns to 1.0 mm
Other Sizes on Request
Wire Density 8.89 g/cm3
Ultimate Strength (≥ MPa):
580-750
Wire Resistance (μΩ.m):
as standard
Wire Elongation (≥ %):
28-30
Surface Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated
Tempers Tempers range from dead soft annealed to ultra spring temper
Welded Wire mesh Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch
Roll Length: 100feet or 150feet
Wire Mesh Weaving Methods plain weave, twill weave, dutch weave
Technique Cold Rolled, hot rolled
Condition M, Y, 1/2Hard
Offered in a wide range of packages including: Spool
Reel
Coil
Bobbin
Carrier
Custom packaging provided from as low as 1lb to 200lb tapered plastics
Form Filler Wire, Flat Wire, Coil Wire, Electrode Wire, Welding Wire, Wire mesh, Knitted wire mesh, filter mesh, mig wire, tig wire, spring wire, stranded and twisted wire
Test Certificates Tensile Testing
Hardness Testing
Metallographic Inspection / Investigation
Corrosion Testing
Chemical Analysis
Wrap Testing
Elevated Temperature Testing
Stress Rupture Testing (Creep)

LogoASME SA580 303 Stainless Steel Wires Equivalent Grades

cta one shape 1
STANDARD WERKSTOFF NR. UNS JIS
SS 303 1.4305 S30300 SUS 303

LogoChemical Composition of Stainless Steel 303 Wires

cta one shape 1
Grade C Mn Si P S Cr Mo Ni N
SS 303 .15 max 2.0 max 1.00 max 0.20 max .15 min 17.0- 19.0 - 8.0 -10.0 -

LogoMechanical Properties of SS 303 Wires

cta one shape 1
Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1400 °C (2550 °F) Psi – 85,000 Psi – 45,000 50%

Bhansali Enterprises Available Variations in Stainless Steel 303 Wires

Bhansali EnterprisesOther Types Of Stainless Steel 303 Wire

  • ASME SA313 Stainless Steel 303 Wire
  • 303 Stainless Steel Spool Wire
  • SS 303 Spring Wire
  • 303 Stainless Steel Cold Heading Wire
  • 303 Stainless Steel Wire Rope
  • Grade 303 SS Wire Rope
  • SS 303 Wire Mesh Manufacturer
  • SS 303 Spring Hard Quality Wire
  • Stainless Steel 303 Tig Wire
  • Stainless Steel 303 Square Wire
  • Stainless Steel 303 Cold Drawn Wire
  • 303 Stainless Steel Industrial Wires
  • UNS S30300 Wire
  • 303 Stainless Steel Ultra Fine Wires
  • Wire Mesh Stainless Steel 303
  • Stainless Steel 303 Crimped Wire Mesh
  • SS 303 Mig Wire
  • ASTM A580 Stainless Steel 303 Woven Wire mesh
  • SS 303 Knitted Wire Mesh
  • 303 Stainless Steel Wire Mesh
  • SS 303 Welding Wire
  • 303 Stainless Steel Wire Bobbin
  • Stainless Steel 303 Netting Wiremesh
  • 303 Stainless Steel Wire cloth
  • SS 303 Knitting Wire
  • 303 Stainless Steel Weld Mesh
  • ASTM A313 303 Stainless Steel Wire
  • 1.4305 Wire

Bhansali EnterprisesStainless Steel 303 Wires Technical Data

Bhansali EnterprisesSS 303 Wires Industrial Application

Applications of Stainless Steel 303 wires are widespread in the manufacturing industry, especially in the production of precision components, fittings, and fasteners. Its superior machinability makes it an excellent choice for applications such as nuts, bolts, screws, bushings, shafts, and couplings. Additionally, it finds usage in various industries, including automotive, aerospace, medical equipment, and electronics.

Shape
about three shape 4
Shape
Shape
  • Oil & Gas Industry

  • Power Plant Generation

  • Marine Industry

  • Petrochemical Industry

  • Chemical Industry

  • Aerospace Industry

  • Sugar Industry

Bhansali EnterprisesStainless Steel 303 Wires Price Details

Prices for SS 303 Wire Products are very affordable. Please click on the request a quote button or Click Here to request the updated price list and ready stock information along with your requirement. Bhansali Enterprise SS 303 maintains a stock of all standard items and can export them at the best price ASME SA580 303 Stainless Steel Wires, Coil Wire, Ribbon Wires, Wiremesh, Wire Bobbin etc.
