Hastelloy C2000 is a nickel-chromium-molybdenum alloy that contains copper and tungsten, designed to offer exceptional resistance to a wide range of corrosive environments. Hastelloy C2000 Wires are a vital form of this alloy, known for their high strength, versatility, and reliability in various industrial applications.

One of the key features of Hastelloy C2000 Wires is their outstanding corrosion resistance. The alloy demonstrates excellent resistance to both uniform and localized corrosion, making it suitable for use in aggressive chemical environments. It can withstand corrosive attacks from acids, alkaline solutions, and oxidizing agents, including sulfuric acid, hydrochloric acid, acetic acid, and chlorine-containing media.

Hastelloy C 2000 Wires

The chemical composition of Hastelloy C2000 wires typically includes nickel (around 57%), chromium (approximately 23%), molybdenum (16%), copper (1.6%), and tungsten (3.3%). This unique blend of elements contributes to the alloy's superior corrosion resistance, high mechanical strength, and excellent weldability.

Machining Hastelloy C2000 wires can be challenging due to their high strength and work-hardening characteristics. Specialized machining techniques, such as using carbide tools and slow speeds, are recommended to achieve the desired results and minimize tool wear.

Bhansali Enterprises Specifications Of Hastelloy C 2000 Wires

Standard ASTM B462 / ASME SB462
Dimensions ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360
Length Cut Lengths: 0.125" to 72"
No Limit on Spooled Lengths
Diameter 0.0004" to 0.040"
10 microns to 1.0 mm
Other Sizes on Request
Wire Density 8.89 g/cm3
Ultimate Strength (≥ MPa):
580-750
Wire Resistance (μΩ.m):
as standard
Wire Elongation (≥ %):
28-30
Surface Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated
Tempers Tempers range from dead soft annealed to ultra spring temper
Welded Wire mesh Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch
Roll Length: 100feet or 150feet
Wire Mesh Weaving Methods plain weave, twill weave, dutch weave
Technique Cold Rolled, hot rolled
Condition M, Y, 1/2Hard
Offered in a wide range of packages including: Spool
Reel
Coil
Bobbin
Carrier
Custom packaging provided from as low as 1lb to 200lb tapered plastics
Form Filler Wire, Flat Wire, Coil Wire, Electrode Wire, Welding Wire, Wire mesh, Knitted wire mesh, filter mesh, mig wire, tig wire, spring wire, stranded and twisted wire
Test Certificates Tensile Testing
Hardness Testing
Metallographic Inspection / Investigation
Corrosion Testing
Chemical Analysis
Wrap Testing
Elevated Temperature Testing
Stress Rupture Testing (Creep)

LogoASME SB462 Hastelloy C 2000 Wires Equivalent Grades

cta one shape 1
STANDARD UNS WNR.
Hastelloy C 2000 N06200 2.4675

LogoChemical Composition of Hastelloy C 2000 Wires

cta one shape 1
Grade Ni Mo Cr Fe W Co Mn C V P Si
Hastelloy C 2000 Remainder 15.0-17.0 14.5-16.5 4.0-7.0 3.0-4.5 2.5 max 1.0 max .01 max .35 max .04 max .08 max

LogoMechanical Properties of Hastelloy C 2000 Wires

cta one shape 1
Grade Tensile Strength Yield Strength Elongation at break
Hastelloy C 2000 690 MPa 310 MPa 45%

Bhansali Enterprises Available Variations in Hastelloy C 2000 Wires

Hastelloy C 2000 Welding Wire

Welding Wire

Hastelloy C 2000 Welding Wire

Hastelloy® Alloy C-2000 Bright Wire

Bright Wire

Hastelloy® Alloy C-2000 Bright Wire

Alloy C2000 Wire Spool

Wire Spool

Alloy C2000 Wire Spool

Nickel Alloy C2000 Wire Coil

Wire Coil

Nickel Alloy C2000 Wire Coil

C-2000 Hastelloy Mig Wire

Mig Wire

C-2000 Hastelloy Mig Wire

Hastelloy C 2000 Woven Wire Mesh

Woven Wire Mesh

Hastelloy C 2000 Woven Wire Mesh

Bhansali EnterprisesOther Types Of Hastelloy C 2000 Wire

  • Hastelloy C 2000 Filler Wire
  • ASME SB462 Hastelloy C 2000 Wire
  • Grade C-2000 Hastelloy Wire Rope
  • Hastelloy C2000 Ultra Fine Wires
  • Hastelloy C 2000 Tig Wire
  • Hastelloy Alloy C2000 Square Wire
  • Hastelloy C-2000 Wire Mesh Manufacturer
  • Hastelloy® Alloy C-2000 Spool Wire
  • Hastelloy C 2000 Welding Wire Price
  • UNS N06200 Wire
  • C-2000 Hastelloy Industrial Wires
  • Alloy C2000 Spring Wire
  • Nickel Alloy C2000 Wire Rope
  • C-2000 Hastelloy Cold Heading Wire
  • Hastelloy C 2000 Cold Drawn Wire
  • Hastelloy® Alloy C-2000 Spring Hard Quality Wire
  • C-2000 Hastelloy Welding Wire
  • ASTM B462 Hastelloy C 2000 Woven Wire mesh
  • 2.4675 Wires
  • Alloy C2000 Knitted Wire Mesh
  • Hastelloy C 2000 Crimped Wire Mesh
  • Nickel Alloy C2000 Wire Bobbin
  • Hastelloy C 2000 Wire
  • Hastelloy Alloy C2000 Wire Mesh
  • Hastelloy C-2000 Weld Mesh
  • Hastelloy C 2000 Coil Wire
  • ASTM B462 C-2000 Hastelloy Wire
  • Hastelloy C2000 Netting Wiremesh
  • Hastelloy C 2000 Knitting Wire
  • Hastelloy® Alloy C-2000 Wire cloth
  • Alloy C2000 Mig Wire
  • Wire Mesh Hastelloy C 2000

Bhansali EnterprisesHastelloy C 2000 Wires Technical Data

Bhansali EnterprisesHastelloy C 2000 Wires Industrial Application

Hastelloy C2000 wires find application in various industries, particularly those involving harsh and aggressive environments. These include chemical processing, petrochemical and gas processing, pharmaceuticals, pulp and paper production, and pollution control systems. The wires are often used in components like springs, seals, bellows, and fasteners due to their corrosion resistance and high strength, which ensures prolonged service life and reduced maintenance costs.

Shape
about three shape 4
Shape
Shape
  • Oil & Gas Industry

  • Power Plant Generation

  • Marine Industry

  • Petrochemical Industry

  • Chemical Industry

  • Aerospace Industry

  • Sugar Industry

Bhansali EnterprisesHastelloy C 2000 Wires Price Details

Prices for Hastelloy C 2000 Wire Products are very affordable. Please click on the request a quote button or Click Here to request the updated price list and ready stock information along with your requirement. Bhansali Enterprise Hastelloy C 2000 maintains a stock of all standard items and can export them at the best price ASME SB462 C2000 Hastelloy Wires, Coil Wire, Ribbon Wires, Wiremesh, Wire Bobbin etc.
