Brass IS 319 Free Cutting Bars
Brass IS 319 free cutting bars refer to a specific type of brass alloy that conforms to the Indian Standard (IS) 319. This standard defines the composition and properties of free-cutting brass bars in India. Free-cutting brass is a type of brass that has excellent machinability, making it easy to cut and shape into various forms.
Table Of Content
Brass IS 319 Round Bar Specifications
| Specifications | ASTM B21/ ASME SB21 |
| Dimension Standard | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Bar Diameter | 0.125" (3.18mm)~2.5" (63.5mm) |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm. Width: 10 to 500mm. |
| Square bar size | 4 to 100mm |
| Rectangular Bars | Size: 33 x 30mm to 295 x 1066mm. Thickness: 3.0 to 12.0mm. |
| Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2 to 495mm Diameter |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients requirements |
| Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Bars Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
Brass IS 319 Bar Equivalent Gardes
| STANDARD | UNS | WERKSTOFF NR. |
| Brass IS 319 Free Cutting | C36000 | - |
Chemical Composition of Brass IS 319 Free Cutting Bars
| Chemical Requirements | Grade |
| Cu | 56 to 58 % |
| Pb | 2 to 3.50 % |
| Fe | 0.3% Max |
| Zn | Balance |
| Other Impurities excel Fe. | 0.75% Max |
Mechanical Properties of Brass IS 319 Free Cutting Bars
| Element | Value |
| Yield Stress | 150 MPa Min. |
| Tensile Strength | 380 MPa Min. |
| Hardness Brinell | 90 to 160 HB |
| Elongation | 18 Min. |
Brass IS 319 Bars Product Features
Available Variations in Brass IS 319 Free Cutting Bars
Hot Rolled
Brass IS 319 Hot Rolled Bar
Cold Rolled
Brass IS 319 Cold Rolled Bar
Round
Brass IS 319 Round Bar
Square Bar
Brass IS 319 Square Bar
Flat Bar
Brass IS 319 Flat Bars
Hex Bar
Brass IS 319 Hexagon Bar
Other Types Of Brass IS 319 Bars
- Brass IS 319 Round Bars
- Brass IS 319 Free Cutting Polished Bar
- Brass IS 319 Free Cutting Hex Bar
- Brass IS 319 Flat Bar
- IS 319 Brass Hexagonal Bar
- UNS C36000 IS 319 Black Bar
- Brass IS 319 Threaded Bar
- Brass IS 319 12mm Bar
- IS 319 Brass C36000 Square Bar
- UNS C36000 Round Bar
- ASTM B21 IS 319 Brass Bar
- Brass IS 319 Industrial Bars
- ASTM B21 Brass IS 319 Round Bar
- Brass IS 319 Free Cutting Round Bars
- Brass IS 319 Hollow Bar
- Brass IS 319 Free Cutting Square Bar
- ASME SB21 Brass IS 319 Bar
- IS 319 Brass Copper Round Bar
- IS 319 Brass C36000 Hex Rod
- UNS C36000 Rectangular Rod
- Brass IS 319 Precision Ground Rod
- ASME SB21 Brass IS 319 Rods
- Brass IS 319 Round Rod
- ASTM B21 IS 319 Brass Rods
- Brass IS 319 Free Cutting Forged Rod
- Brass IS 319 C36000 Flat Rod
- UNS C36000 Rectangular Bars
- Brass IS 319 Free Cutting Rod Stock
- Brass IS 319 Free Cutting C36000 Rods
- Brass UNS C36000 T-Rod
- IS 319 Brass Hot Rolled Bars
- UNS C36000 Round Rod
- ASME SB21 IS 319 Half-Round Rods
- ASME SB21 IS 319 Forged Bar
- IS 319 Brass Free Cutting Round Rods
- Brass IS 319 Cold Finish Round Rods
Brass IS 319 Free Cutting Bars Technical Data
Brass IS 319 Bars Industrial Application
Brass IS 319 free cutting bars find applications in a wide range of industries
and products, including:
1. Fasteners: They are commonly used to manufacture nuts, bolts,
screws, and other fasteners due to their excellent machinability and corrosion
resistance.
2. Electrical and Electronics: Brass bars are used to make electrical
connectors, terminals, and various components in electronics and electrical equipment.
3. Plumbing and Fittings: In plumbing and sanitary fittings, Brass IS
319 bars are used for making valves, faucets, couplings, and other plumbing components.
4. Automotive Industry: These bars are used in the automotive sector to
produce parts like gears, bushings, and fittings.
5. Precision Components: Due to their machinability, these bars are
employed in the manufacturing of precision components for instruments, clocks, and
watches.
6. Locks and Hardware: Brass free cutting bars are used for making
locks, keys, and various types of hardware.
-
-
Power Plant Generation
-
Marine Industry
-
Petrochemical Industry
-
Chemical Industry
-
Aerospace Industry
-
Sugar Industry
Brass IS 319 Free Cutting Bar Price Details
Prices for Copper Bars Products are very affordable. Please click on the request a quote button or Click Here to request the updated price list and ready stock information along with your requirement. Bhansali Enterprise Copper maintains a stock of all standard items and can export them at the best price ASME SB21 Copper Commercial Grade ETP Bars, Round Bars, Flat Bars, Hex Bars, Hor Rolled Bars, Cold Rolled Bars etc.
