Inconel sheet plate in Qatar
Inconel Sheet Plate In Qatar, Inconel Sheet, Inconel Plate, Inconel Plate Suppliers, Inconel Sheet Suppliers
Bhansali Enterprise is one of the prominent manufacturers as well as suppliers of the Inconel Sheet Plates in Qatar which is known for its quality and service. The Inconel Sheet Plates we offer are produced to provide the best sturdiness and utility in several sectors.
Inconel alloys, particularly those used in our sheet plates, are famous for their high temperature, oxidation and corrosion resistance. Our Nickel Chromium based alloy Inconel Sheet Plates are built to last in the harshest environment while maintaining their durability. These properties make them suitable for use in areas with high heat, pressure and corrosive atmospheres.
The following are some of the characteristics of our Inconel Sheet Plates: high oxidation and carburisation resistance, which make them very durable. Our sheet plates are ideal for aerospace parts, gas turbine and chemical processing industries due to the high-temperature strength and good creep resistance of Inconel alloys. They also have excellent characteristics in thermal fatigue and thermal cycling.
Inconel Sheet Plate is manufactured to the highest standard and is therefore very much controlled for quality. In our strict quality assurance, the mechanical properties of the products, the corrosion resistance and dimensions have been examined. All the activities from the time the raw materials are purchased to the last check on the final products are done very carefully to avoid compromising the quality of the products.
These Inconel Sheet Plates are widely used in the aerospace, energy, and petrochemical industries to work with high performance and reliability. Because of their compactness, they are applied in areas where the materials’ reliability and durability are crucial.
We know how valuable it is to offer the best Inconel Sheet Plates to give good value for the money. Our team is always ready to provide technical assistance and design a specific product for you.
Inconel Sheet Plate Specifications in Qatar
| Standards | ASTM B443/ ASME SB443 |
| Dimensions | ASTM, ASME, and API |
| Sheets Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets Plates Thickness | 4mm-100mm |
| Sheets Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | No.1, 2B, BA, 8K Mirror, Hairline, satin (Met with Plastic Coated) Embossed, brush, No.4, HL, matt, pvc etc. |
| Value added services | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Hardness | Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
| Form | Coils, Foils, Rolls, Strip, Flats, Blank (Circle), Ring (Flange) |
Available Variations in Inconel Sheet Plate in Qatar
Inconel Sheets
Inconel Plates
Inconel Coils
Inconel Strips
Inconel Foils
Inconel Circle
Inconel Sheet Plate Equivalent Gardes in Qatar
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Inconel 718 | 2.4668 | N07718 | – | – | – | – | – |
Chemical Composition of Inconel Sheet Plate in Qatar
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
Mechanical Properties of Inconel Sheet Plate in Qatar
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Other Types Of Inconel Sheet Plate in Qatar
- Inconel 600 Coils Price
- Alloy 625 Coils
- Inconel Alloy 800 Sheets
- Inconel Alloy 820 Plates
- Inconel x-750 Plate
- Inconel 700 Plates
- Inconel 800 Sheets
- ASTM B168 Inconel Alloy 825 Sheets
- Nickel Alloy 718 Shim Sheets
- UNS N06601 Sheets
- Inconel 2.4816 Coils
- Inconel Alloy 925 HR Coils
- Inconel 600 Plate
- Nickel Alloy 718 Sheets
- Inconel 700 Sheet Suppliers
- Inconel Alloy 600 Perforated Sheet
- UNS N06600 Coils Supplier
- Inconel Alloy x-750 Coil
- Nickel Alloy 620 Sheets
- 2.4816 Plates
- N06600 Inconel Hot Rolled Plate
- Inconel 718 Slit Coils
- Inconel Alloy 725 Circle
- Alloy x-750 Strips
- Inconel 800 Plate Price
- Inconel 825 Coil
- Inconel Alloy 600 Shim Coils
- Inconel 600 Cold Rolled Coils
- ASME SB168 Inconel Alloy 700 Plate
- Inconel 725 Sheet
- Alloy 601 CR Plate
- Nickel Alloy 600 Plate
- UNS N06600 Rings
- Inconel 2.4851 Sheets
- Inconel Alloy 600 Foils
- Nickel Alloy 601 Rolls
Inconel Sheet Plate Industrial Application in Qatar
- Oil & Gas Industry
- Power Plant Generation
- Marine Industry
- Petrochemical Industry
- Chemical Industry
- Aerospace Industry
- Sugar Industry
- Pharmaceutical Equipment
- Pulp and Paper Industry
- Gas Processing
- Specialty Chemicals
- Off-Shore Oil Drilling Companies
