Inconel Sheet Plate In Iraq, Inconel Sheet, Inconel Plate, Inconel Plate Suppliers, Inconel Sheet Suppliers
We at Bhansali Enterprise are one of Iraq’s leading manufacturers and suppliers of Inconel Sheet Plates. They are of superior quality and provide high performance in the areas where high-quality products are required. Inconel Sheet Plates are manufactured to offer high strength, excellent corrosion resistance, and durability in various environments, making them suitable for use in several industries.
Our Inconel Sheet Plates are made from the finest Inconel alloy with some of the best qualities like oxidation resistance, corrosion, and high temperature. This nickel-chromium-based alloy provides high stability and performance when the equipment is in a high-temperature and corrosive environment. The material we use for our sheet plates ensures they do not change their properties and will be as strong as needed in aerospace, chemical, and power generation industries.
Our Inconel Sheet Plates are made from the finest Inconel alloy with some of the best qualities like oxidation resistance, corrosion, and high temperature. This nickel-chromium-based alloy provides high stability and performance when the equipment is in a high-temperature and corrosive environment. The material we use for our sheet plates ensures they do not change their properties and will be as strong as needed in aerospace, chemical, and power generation industries.
Our Inconel Sheet Plates features include high tensile strength, good fatigue strength, and thermal and chemical stability. Therefore, they are appropriate for use in situations with high temperatures, pressure, and corrosive atmospheres. Also, the plates possess excellent weldability and formability for various fabrication procedures.
Pricing and quality are other factors considered at Bhansali Enterprise. Inconel Sheet Plates available with us are checked for quality from the manufacturing stage to the final stage. Mechanical, corrosion, and dimensional tests are carried out on each plate to ensure that each plate meets the performance standards. Inconel Sheet Plates are used in several fields, and some of their uses are in heat exchangers, gas turbines, and reactor cores. Because of the improved properties, they can be applied in projects requiring high-performance material with high resistance to various conditions.
Our vision is to provide the best quality products to customers. The Inconel Sheet Plates that we have in our stock is a true reflection of our commitment and hard work towards providing our clients with the best, which makes us the preferred partner for businesses in Iraq and other parts of the world.
Pricing and quality are other factors considered at Bhansali Enterprise. Inconel Sheet Plates available with us are checked for quality from the manufacturing stage to the final stage. Mechanical, corrosion, and dimensional tests are carried out on each plate to ensure that each plate meets the performance standards. Inconel Sheet Plates are used in several fields, and some of their uses are in heat exchangers, gas turbines, and reactor cores. Because of the improved properties, they can be applied in projects requiring high-performance material with high resistance to various conditions.
Our vision is to provide the best quality products to customers. The Inconel Sheet Plates that we have in our stock is a true reflection of our commitment and hard work towards providing our clients with the best, which makes us the preferred partner for businesses in Iraq and other parts of the world.
Inconel Sheet Plate Specifications in Iraq
| Standards | ASTM B443/ ASME SB443 |
| Dimensions | ASTM, ASME, and API |
| Sheets Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets Plates Thickness | 4mm-100mm |
| Sheets Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface Finish | No.1, 2B, BA, 8K Mirror, Hairline, satin (Met with Plastic Coated) Embossed, brush, No.4, HL, matt, pvc etc. |
| Value added services | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Hardness | Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
| Form | Coils, Foils, Rolls, Strip, Flats, Blank (Circle), Ring (Flange) |
Available Variations in Inconel Sheet Plate in Iraq
Inconel Sheets
Inconel Plates
Inconel Coils
Inconel Strips
Inconel Foils
Inconel Circle
Inconel Sheet Plate Equivalent Gardes in Iraq
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Inconel 718 | 2.4668 | N07718 | – | – | – | – | – |
Chemical Composition of Inconel Sheet Plate in Iraq
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
Mechanical Properties of Inconel Sheet Plate in Iraq
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Other Types Of Inconel Sheet Plate in Iraq
- Inconel 600 Coils Price
- Alloy 625 Coils
- Inconel Alloy 800 Sheets
- Inconel Alloy 820 Plates
- Inconel x-750 Plate
- Inconel 700 Plates
- Inconel 800 Sheets
- ASTM B168 Inconel Alloy 825 Sheets
- Nickel Alloy 718 Shim Sheets
- UNS N06601 Sheets
- Inconel 2.4816 Coils
- Inconel Alloy 925 HR Coils
- Inconel 600 Plate
- Nickel Alloy 718 Sheets
- Inconel 700 Sheet Suppliers
- Inconel Alloy 600 Perforated Sheet
- UNS N06600 Coils Supplier
- Inconel Alloy x-750 Coil
- Nickel Alloy 620 Sheets
- 2.4816 Plates
- N06600 Inconel Hot Rolled Plate
- Inconel 718 Slit Coils
- Inconel Alloy 725 Circle
- Alloy x-750 Strips
- Inconel 800 Plate Price
- Inconel 825 Coil
- Inconel Alloy 600 Shim Coils
- Inconel 600 Cold Rolled Coils
- ASME SB168 Inconel Alloy 700 Plate
- Inconel 725 Sheet
- Alloy 601 CR Plate
- Nickel Alloy 600 Plate
- UNS N06600 Rings
- Inconel 2.4851 Sheets
- Inconel Alloy 600 Foils
- Nickel Alloy 601 Rolls
Inconel Sheet Plate Industrial Application in Iraq
- Oil & Gas Industry
- Power Plant Generation
- Marine Industry
- Petrochemical Industry
- Chemical Industry
- Aerospace Industry
- Sugar Industry
- Pharmaceutical Equipment
- Pulp and Paper Industry
- Gas Processing
- Specialty Chemicals
- Off-Shore Oil Drilling Companies
