SS 316 Wire in Iraq
SS 316 Wire In Iraq, SS 316 Wire, SS Wire Manufacturers
Bhansali Enterprise is one of the leading SS 316 Wire manufacturers and suppliers in Iraq, and it is committed to delivering only the best quality products that can perform well in tough environments. The SS 316 Wire is designed to give the optimum strength, durability and corrosion resistance to the environment and hence is utilised in different fields.
SS 316 Wire is produced from austenitic stainless steel; it contains more molybdenum than SS 304. This enhancement protects against corrosion, particularly where chloride is involved, such as in marine, chemical, and pharmaceutical industries. This characteristic makes the alloy very suitable for conditions requiring high resistance to pitting, crevice corrosion and stress corrosion cracking.
Some of the features of our SS 316 Wire are high tensile strength, good corrosion and oxidation resistance, and good high temperature characteristics. The wire also has good chemical resistance to most chemicals in use, such as acids and chlorides. Also, it has good weldability and formability; therefore, it is used in several engineering and manufacturing industries.
Quality assurance is another factor that is considered in producing SS 316 Wire at Bhansali Enterprise. Every batch is strictly checked and tested to produce the best quality in the market. The quality control measures involve mechanical, dimensional, and corrosion tests to ensure that every wire produced meets the required standard.
Some of our SS 316 Wire applications include marine equipment, chemical processing equipment, medical instruments, and many more. Because of its high resistance to corrosive conditions, it is applied in projects that call for high performance materials.
Our primary goal is to make the products delivered to the target markets as desired by the consumers or even better. The SS 316 Wire is another example of our commitment to quality and innovation, which helped us become a leading supplier for companies in Iraq and the global market.
SS 316 Wire Specifications in Iraq
| Standard | ASTM A580, A313, A555, A493 / ASME SA580, SA313, SA555, SA493, AMS 5514 |
| Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
| Length | Cut Lengths: 0.125″ to 72″ No Limit on Spooled Lengths |
| Diameter | 0.0004″ to 0.040″ 10 microns to 1.0 mm Other Sizes on Request |
| Wire Density | 8.89 g/cm3 |
|
580-750 |
|
as standard |
|
28-30 |
| Surface | Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Welded Wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet |
| Wire Mesh Weaving Methods | plain weave, twill weave, dutch weave |
| Technique | Cold Rolled, hot rolled |
| Condition | M, Y, 1/2Hard |
| Offered in a wide range of packages including: | Spool Reel Coil Bobbin Carrier Custom packaging provided from as low as 1lb to 200lb tapered plastics |
| Form | Filler Wire, Flat Wire, Coil Wire, Electrode Wire, Welding Wire, Wire mesh, Knitted wire mesh, filter mesh, mig wire, tig wire, spring wire, stranded and twisted wire |
| Test Certificates | Tensile Testing Hardness Testing Metallographic Inspection / Investigation Corrosion Testing Chemical Analysis Wrap Testing Elevated Temperature Testing Stress Rupture Testing (Creep) |
Available Variations in Stainless Steel 316 Wire in Iraq
SS 316 Welding Wire in Iraq
SS 316 Bright Wire in Iraq
Stainless Steel 316 Wire in Iraq
Stainless Steel Wire 316 Coil in Iraq
SS 316 Mig Wire in Iraq
SS 316 Woven Wire Mesh in Iraq
SS 316 Wire Equivalent Grades in Iraq
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Chemical Composition of SS 316 Wire in Iraq
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
Mechanical Properties of SS 316 Wire in Iraq
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Other Types Of Stainless Steel 316 Wire in Iraq
- 316 Stainless Steel Spool Wire
- UNS S31600 Wire
- SS 316 Spring Wire
- SS 316 Wire Mesh Manufacturer
- Stainless Steel 316 Square Wire
- 316 Stainless Steel Industrial Wires
- DIN 1.4401 Wire
- Stainless Steel 316 Cold Drawn Wire
- ASME SA313 Stainless Steel 316 Wire
- 316 Stainless Steel Cold Heading Wire
- SS 316 Spring Hard Quality Wire
- 316 Stainless Steel Ultra Fine Wires
- 316 Stainless Steel Wire Rope
- Grade 316 SS Wire Rope
- Stainless Steel 316 Tig Wire
- SS 316 Knitted Wire Mesh
- SS 316 Mig Wire
- 316 Stainless Steel Wire Bobbin
- SS 316 Welding Wire
- DIN 1.4401 Wire Mesh
- Stainless Steel 316 Netting Wiremesh
- 316 Stainless Steel Weld Mesh
- Stainless Steel 316 Crimped Wire Mesh
- Wire Mesh Stainless Steel 316
- ASTM A313 316 Stainless Steel Wire
- SS 316 Knitting Wire
- ASTM A580 Stainless Steel 316 Woven Wire mesh
- UNS S31600 Wires
- 316 Stainless Steel Wire Mesh
- 316 Stainless Steel Wire cloth
SS 316 Wire Industrial Application in Iraq
- Oil & Gas Industry
- Power Plant Generation
- Marine Industry
- Petrochemical Industry
- Chemical Industry
- Aerospace Industry
- Sugar Industry
- Pharmaceutical Equipment
- Pulp and Paper Industry
- Gas Processing
- Specialty Chemicals
- Off-Shore Oil Drilling Companies
