Inconel Round Bar in Saudi Arabia
Inconel Round bar in Saudi Arabia, Inconel Round bar, Inconel Round bar suppliers
Bhansali Enterprise is one of the prominent sources for Inconel Round Bars in Saudi Arabia which is well known for offering a variety of products that match the requirements of various industries. Our Inconel Round Bars are produced to exact specifications for high strength, corrosion resistance and toughness for aerospace, marine, chemical processing and power generation applications.
Inconel Round Bars are made from Inconel alloys that are Nickel-Chromium based super alloy that is used in severe operating environment. These alloys are designed to have the same structural and mechanical characteristics as the base material and, at the same time, to be resistant to oxidation and corrosion at high temperature and under the conditions of mechanical loading. Because of the mentioned characteristics Inconel is applied in many fields where high performance and durability of the material are required.
Quality is our top priority. Quality is controlled from the manufacturing stage and our Inconel Round Bars are produced to meet the international standards and the needs of the customers. The quality control measures include the chemical test, mechanical test, and dimensional test. We also carry out non destructive tests in a bid to establish if there are any defects.
There are many applications of our Inconel Round Bars and they are all vital. In aerospace industries, they are used in fabrication of high strength parts such as the jet engine parts, turbine blades and exhaust systems where high performance at high temperatures is expected. Inconel Round Bars can be used in marine industry since they have high resistance to seawater, they can be used in ships construction, offshore platforms, and marine devices. It is applied in the chemical processing industry in apparatus that comes into contact with corrosive materials like reactors, heat exchangers, and pipes.
If you are planning to buy Inconel Round Bars from us, then you are assured of getting quality products from a company that cares for its customer. Because of our experience and our dedication to research and development, we are able to provide products that are efficient and reliable.
Inconel Round Bar Specifications in Saudi Arabia
| Specifications : | ASTM B166 / ASME SB166 |
| Dimensions : | ASTM, ASME and API |
| Size : | 10 mm To 100 mm Dia in 100 mm TO 6000 mm Length. |
| Length : | 3 to 6 meter, Custom Cut Lengths |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Form : | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wiremesh, Billet, Ingot, Forging Etc., |
| Condition : | Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished |
Available Variations in Inconel Round Bar in Saudi Arabia
Inconel Squar Bar
Inconel Flat Bar
Inconel Hexagon Bar
Inconel Hot Rolled Bar
Inconel Cold Rolled Bar
Inconel Round Bar
Inconel Round Bar Equivalent Gardes in Saudi Arabia
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Inconel 718 | 2.4668 | N07718 | – | – | – | – | – |
Chemical Composition of Inconel Round Bar in Saudi Arabia
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
Mechanical Properties of Inconel Round Bar in Saudi Arabia
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Other Types Of Inconel Round Bar in Saudi Arabia
- 2.4816 Round Bar
- Inconel 600 Polished Bar
- Inconel Alloy 601 Threaded Bar
- Inconel 718 Square Bar
- 600 Inconel Alloy Round Bar
- Inconel x-750 Round Bar
- Inconel Alloy 1.4307 Square Bar
- ASME SB166 600 Inconel Bar
- Inconel 925 Hollow Bar
- ASTM B166 Alloy 601 Bar
- Inconel Alloy 2.4851 Round Bars
- UNS N06600 Round Bar
- WNR 2.4851 Industrial Bars
- Inconel 800 Hexagonal Bar
- 825 Inconel 12mm Bar
- 601 Alloy Round Bars
- Inconel x-750 Hex Bar
- ASTM B166 Alloy 718 Round Bar
- Inconel Alloy 800 Round Bar
- 601 Alloy T-Rod
- Inconel 600 Cold Finish Round Rods
- 2.4851 Round Rod
- UNS N06601 Rectangular Rod
- Inconel Alloy 2.4816 Rods
- Inconel 825 Rod Stock
- ASME SA 276 Alloy 600 Rods
- Inconel 601 Forged Rod
- Inconel Alloy 925 Round Rods
- Inconel 601 Hex Rod
- Inconel 1.4307 Round Rod
- Steel x-750 Round Rod
- 718 Inconel Alloy Precision Ground Rod
- Inconel Alloy 601 Round Rod
- ASME SB166 Alloy 600 Round Rod
- Inconel 625 Flat Rod
- ASME SB166 Alloy 600 Half-Round Rods
- UNS N06601 Round Rod
- Astm B166 Alloy 601 Inconel Rods
Inconel Round Bar Industrial Application in Saudi Arabia
- Oil & Gas Industry
- Power Plant Generation
- Marine Industry
- Petrochemical Industry
- Chemical Industry
- Aerospace Industry
- Sugar Industry
- Pharmaceutical Equipment
- Pulp and Paper Industry
- Gas Processing
- Specialty Chemicals
- Off-Shore Oil Drilling Companies
